Qinghao Cheng* and Lei Li
Department of Anesthesiology, China Meitan General Hospital, Beijing 100028, China
Received: 07 April, 2015; Accepted: 13 April, 2015; Published: 15 April, 2015
*Corresponding author:
Qinghao Cheng, Department of Anesthesiology, China Meitan General Hospital, Beijing 100028, China, Email: @
Cheng Q, Li L (2015) Brochoscopy Intervention using Laryngeal Mask Airway in Infant for Severe Airway Stenosis. Glob J Anesthesiol 2(1): 012-013. DOI: 10.17352/2455-3476.000009
© 2015 Cheng Q, et al. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
Bronchoscopy intervention; Laryngeal mask airway; Infant anesthesia; Airway stenosis


Fibreoptic bronchoscopy (FB) and laryngeal mask airway (LMA) have been used successfully in children since the early 1980s [11. Wood RE, Postma D (1988) Endoscopy of the airway in infants and young children. J Pediatr 112: 1-6.,22. Brain AI (1983) The laryngeal mask-a new concept in airway management. Br J Anaesth 55: 801-805.]. The paediatric fibreoptic bronchoscopy visa laryngeal mask airway (LMA) in general anesthesia was established in 1990s [33. Smyth AR, Bowhay AR, Heaf LJ, Smyth RL (1996) The laryngeal mask airway in fibreoptic bronchoscopy. Arch Dis Child 75: 344-345.,44. Wood RE (1996) Pediatric bronchoscopy. Chest Surg Clin N Am 6: 237-251.]. Although previous studies have shown some experience on FB in infant, conclusive effects on bronchoscopy intervention are unknown. We report the use of laryngeal mask airway (LMA) to guide electric bronchoscopy interventions (EBI) while maintaining an adequate depth of anesthesia and effective ventilation in small infant who was diagnosed of having severe airway stenosis from computed tomography (CT) scan.

Case Reports

A five-month-old female infant weighing 6kg, was arranged to EBI using LMA. She was hospitalized because of caugh one month ago. Preoperative examination: Karnofsky score 20 points,inspiratory stridor, intermittment cyanosis. CT and FB revealed 80% tracheal obstruction (Figure 1A). The stenosis was arising from trachea membrance 20 mm below the vocal cord. The stenotic lesion had extended from the origin of tracheal bronchus to the carina (length of stenosis was 11 mm), without involving the carina. The luminal diameter at the narrowest of the trachea was 2 mm. arterial blood gas analysis were as follows: pH 7.35; PaCO2, 6.58 kpa; PaO2, 7.70 kpa; and SpO2, 92%. Laboratory investigation revealed no significant findings. After consulting with anesthesitists, endoscopists, surgeons and radiologists, EBI for tracheal stenosis was scheduled though LMA because of her poor respiratory condition.

Anesthetic induction, and maintenance

No pre-medicated dugs were treated before the induction of anesthesia. The patient was monitored using a non-invasive measurement of blood pressure, electrocardiogram, pulse oxymetry, endtidal carbon dioxide concentration. Anesthesia was induced with intravenous sufentany (1ug/kg) lidocaine (2mg/kg), propofol (3mg/kg), rocuronium (0.6mg/kg) and slow infusion of atropine (0.02mg/kg), followed by titration of propofol (812mg·kg-1·h-1), and remifentanil (0.2 0.4ug·kg-1·min-1). A 2#LMA was then inserted. The size of the LMA was chosen based on the manufacturer's guide- lines and the diameter of electric bronchoscope. The infusion rate of propofol and remifentanil were titrated with baseline vital signs.

Ventilation in patients was performed through the main entry of the Y-connector between the LMA and the anesthesia circuit(Figure 1B). Jet ventilation was applied through the side entry of the Y-connector in patient with jet ventilator (Jiangxiteli Medical Instruments, China). Initial settings were as follows: driving pressure 3 kg/cm2, respiratory rate 16 to 24 bpm, and inspiratory fraction 50%. Inspired oxygen fraction (Fio2) was set at 100% in the whole intervention. Settings were modified during the procedure to achieve both an optimal gas exchange. Ventilation was monitored following continuous pulse oximetry and intermittent blood gas. When SPO2 lower 95%, we stopped therapy and manually ventilation until SPO2 100mm Hg if therapy permitted.

Technique of bronchoscopic intervention

Procedures were performed with electric flexible bronchoscopes (Pantex, Janpan, bronchoscopes of external diameters 4.9 mm and 2.8mm) through the 2# LMA. When managing airway obstruction, endoscopists recanalized the obstructed lumen and relieve the patient's symptoms [55. Gorden JA, Ernst A (2009) Endoscopic management of central airway obstruction. Semin Thorac Cardiovasc Surg 21: 263-273.](Figure 1C). Various methods for controlling the airway have been established to solve this problem, such as the electric loop, cryoprobe, argon plasma coagulation. The operation took 30 minutes (Figure 1D). After operation, the findings of the postoperative arterial blood gas analysis were as follows: pH 7.01; PaCO2 ,15.33KPa; PaO2, 10.13KPa and SpO2, 93%.we remove LMA and insert the endotracheal 3.5# tube. The patient was transferred to the intensive care unit. 6 hours after the surgery, endotracheal tube was removed. The pathological diagnosis is hemangioma. A week later, the patient discharged. After a year follow-up, the patient has no breath suppress symptoms.

  1. avatar
    Figure 1:

    A) CT showing airway stenosis. B) Y-connector. C) Bronchoscopy photography showing a narrowest portion of the trachea. D) Bronchoscopy photography showing canalization of the trachea.


EBI under general anesthesia is difficult and hazardous in small infant. Although a rigid bronchoscope is suitable for examing the larynx under general anesthesia, it is more hazardous to tissues around the larynx than fiberscopic procedures. Thus, fiberoptic bronchoscopy with the LMA should fulfill both the requirements of diagnosis and of safety for children [33. Smyth AR, Bowhay AR, Heaf LJ, Smyth RL (1996) The laryngeal mask airway in fibreoptic bronchoscopy. Arch Dis Child 75: 344-345.,66. Bandla HP, Smith DE, Kiernan MP (1997) Laryngeal mask airway facilitated fibreoptic bronchoscopy in infants. Can J Anaesth 44: 1242–1247.,77. Baraka A, Choueiry P, Medawwar A (1995) The laryngeal mask airway for fibreoptic bronchoscopy in children. Paediatr Anaesth 5: 197-198.].

By contrast, EBI through an endotracheal tube under general anesthesia is a safe procedure, but narrow airway cannot be passed through an appropriately sized bronchoscope. The smallest bronchoscope which has a biopsy channel is 4.9 mm in diameter and endotracheal tube of at least 7 mm in diameter. This would effectively mean that transbronchial intervention could only be performed in children over 8 years of age [33. Smyth AR, Bowhay AR, Heaf LJ, Smyth RL (1996) The laryngeal mask airway in fibreoptic bronchoscopy. Arch Dis Child 75: 344-345.]. The smallest bronchoscope with a suction channel is 2.8 mm in diameter and requires and endotracheal tube of at least 4.5 mm in diameter. The lower age limit for bronchoalveolar lavage would then be 1 years. So the size 2 LMA (internal diameter 7 mm) is suitable for use in infants.

Most centers avoid bronchoscopy in children under light sedation because the results will often remain unsatisfactory because of cough and movement. Also, in our experience, significant problems during the procedure are usually due rather to a too shallow and almost never to a too deep level of anesthesia/sedation. A recent review of this topic shows a practical approach to these procedures [88. Dilos BM (2009) Anesthesia for pediatric airway endoscopy and upper gastrointestinal endoscopy. Int Anesthesiol Clin 47: 55-62.]. Even with deep sedation, protective airway reflexes must be suppressed to allow the passage of the bronchoscope through the glottis, generating a similar level of aspiration risk as during anesthesia [99. Nicolai T (2011) The role of rigid and flexible bronchoscopy in children. Paediatric Respir Rev 12: 190-195.]. In line with practice in children anesthesia in our department, we use general anaesthetic, rather than sedation, for all interventions. This enables better monitoring and airway control. So we also advocate that bronchoscopy interventions in children should only be performed under general anaesthetic [1010. Scott JP, Higenbottam TW, Smyth RL, Whitehead B, Helms P, et al. (1990) Transbronchial biopsies in children after heart-lung transplantation. Pediatrics 86: 698-702.].

During this case postoperative blood gas PaO2, PaCO2 higher indicate that mechanical ventilation is inadequate. The reasons of inadequate ventilation include tracheal diameter thin, relative large bronchoscope, and secretions, blood, shedding tiny tissues etc. When SPO2 lower than 95%, we stopped the intervention and begin handal ventilation until SPO2 100%. After pause the therapy, oxygen saturation rate was 78. This indicates that infants have limited oxygen reserve, especially collapse of the small airways and an interval of hypoxemia [1111. Nadkarni V (2000) Ventricular fibrillation in the asphyxiated piglet model. In: Quan L, Franklin WH, eds. Ventricular Fibrillation: a Pediatric Problem. Armonk, NY: Futura Publishers 43-54.].

Although this case was performed through LMA, other devices should be prepared. From our limited experience, the following features should be focused on. (1) Adjust patient, head low-feet high position, avoid aspiration. (2) Anesthesiologist should be familiar with anesthetic airway control and prepare different sizes of tubes, establish emergency airway. This is critical when managing patients with airway obstruction. (3) During interventions, certified and fully trained nurse is required to the safe procedure.

In conclusion, the LMA is useful for fiberoptic bronchoscopy of children with severe subglottic stenosis. The anesthesiologist must be responsible for the airway in the whole intervention and control the airway quickly when emergency.


We would like to thank all the individuals who participated in this study for their support.
